Swiss Army Knife Ultra
$132.99
Incredibly compact, indoor/outdoor AP with versatile mounting options and long-range external antenna support.
Ship Charge Will Display As Free Until Ship Address / Location Is Provided To Calculate Ship Charge
Your Payments Are Securely Processed By PayPal Using SSL Technologies.
Please note! Ship charge will display as free until ship address / location is provided to calculat
Mechanical | |
---|---|
Dimensions | 137 x 84 x 34 mm (5.4 x 3.3 x 1.3") |
Weight | 173 g (6.1 oz) |
Enclosure material | UV-stabilized polycarbonate |
Mount material | Polycarbonate, SGCC steel, plastic |
Pole mount diameter | 1~2" on pipe outer diameter |
Wind survivability | 33.2 N at 200 km/h (7.5 lbf at 125 mph) |
Weatherproofing | IPX6 |
Hardware | |
Networking interface | (1) GbE RJ45 port |
Management interface | Ethernet |
Power method | PoE |
Power supply | UniFi PoE Switch |
Supported voltage range | 44—57V DC |
Max. power consumption | 8W |
Max. TX power 2.4 GHz 5 GHz 6 GHz |
20 dBm 20 dBm – |
MIMO 2.4 GHz 5 GHz 6 GHz |
2 x 2 2 x 2 – |
Throughput rate 2.4 GHz 5 GHz 6 GHz |
300 Mbps 866.7 Mbps – |
Antenna gain 2.4 GHz 5 GHz 6 GHz |
4.7 dBi 6.1 dBi – |
Antenna | (1) Internal antenna (2) RP-SMA connectors for optional external antennas |
LEDs | (1) Power: white/blue (4) Mesh signal: blue |
Button | Factory reset |
Mounting | Wall, ceiling, pole (Included) |
Ambient operating temperature | -40 to 60° C (-40 to 140° F) |
Ambient operating humidity | 5 to 95% noncondensing |
Certifications | CE, FCC, IC |
Software | |
WiFi standards | 802.11a/b/g/n/ac |
Wireless security | WPA-PSK, WPA-Enterprise (WPA/WPA2, TKIP/AES) |
BSSID | 8 per radio |
VLAN | 802.1Q |
Advanced QoS | Per-user rate limiting |
Guest traffic isolation | Supported |
Concurrent clients | 200+ |
Supported Data Rates | |
802.11a | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
802.11b | 1, 2, 5.5, 11 Mbps |
802.11g | 6, 9, 12, 18, 24, 36, 48, 54 Mbps |
802.11n (WiFi 4) | 6.5 Mbps to 300 Mbps (MCS0 - MCS15, HT 20/40) |
802.11ac (WiFi 5) | 6.5 Mbps to 866.7 Mbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80) |
Application Requirements | |
UniFi Network | Web: Version 8.0.7 and later iOS™: Version 10.11.1 and later Android™: Version 10.10.1 and later |
