U6 Mesh Pro

$0.00
Indoor/outdoor WiFi 5 AP with 6 spatial streams and extended signal range for maximum coverage.

wifi5.svgWiFi 5

streams.svg6 spatial streams

floorplan.svg185 m² (2,000 ft²) coverage

connection.svg250+ connected devices

poe.svgPowered using PoE*

uplink.svgGbE uplink

mount.svgVersatile wall and pole mounting

waterdrop.svgWeatherproof (outdoor exposed)

*PoE power adapter included with single unit purchase

Quantity
Out-of-Stock

100% secure payments
local_shipping Estimate Shipping arrow_drop_down

There are not enough products in stock

Loading...



Ship Charge Will Display As Free Until Ship Address / Location Is Provided To Calculate Ship Charge



Your Payments Are Securely Processed By PayPal Using SSL Technologies.



Please note! Ship charge will display as free until ship address / location is provided to calculat

U6 Mesh Pro
Mechanical
Dimensions 343.2 x 181.2 x 60.2 mm (13.5 x 7.1 x 2.4")
Weight 819 g (1.8 lb)
Enclosure material UV-stabilized polycarbonate
Mount material Aluminum alloy, steel
Pole mount diameter 1~2.5" on pipe outer diameter
Weatherproofing IPX6
Hardware
Networking interface (2) GbE RJ45 ports
Management interface Ethernet
WiFi
Power method PoE
Power supply UniFi PoE switch
48V, 0.5A PoE adapter (Included)
Supported voltage range 42.5—57V DC
Max. power consumption 9W
Max. TX power
2.4 GHz
5 GHz
6 GHz

22 dBm
27 dBm
MIMO
2.4 GHz
5 GHz
6 GHz

2 x 2 (DL/UL MU MIMO)
2 x 2 (DL/UL MU-MIMO)
Throughput rate
2.4 GHz
5 GHz
6 GHz

573.5 Mbps
2.4 Gbps
Antenna gain
2.4 GHz
5 GHz
6 GHz

8 dBi
8 dBi
LEDs White/blue
Button Factory reset
Mounting Wall, pole (Included)
Ambient operating temperature -30 to 60° C (-22 to 140° F)
Ambient operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC
Software
WiFi standards 802.11a/b/g/n/ac/ax
Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3)
BSSID 8 per radio
VLAN 802.1Q
Advanced QoS Per-user rate limiting
Guest traffic isolation Supported
Concurrent clients 350+
Supported Data Rates
802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11b 1, 2, 5.5, 11 Mbps
802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps
802.11n (WiFi 4) 6.5 Mbps to 300 Mbps (MCS0 - MCS15 , HT 20/40)
802.11ac (WiFi 5) 6.5 Mbps to 1.7 Gbps (MCS0 - MCS9 NSS1/2, VHT 20/40/80/160)
802.11ax (WiFi 6) 7.3 Mbps to 2.4 Gbps (MCS0 - MCS11 NSS1/2, HE 20/40/80/160)
Application Requirements
UniFi Network Version 8.1.127 and later
U6-Mesh-Pro
